Factory price transflective LCD display with 160x160 dots SPI interface LCD
PRODUCT DESCRIPTION
1. 160x160dots
2. Parallel interface
3. Ultra high contrast, YG & White LED backlight as option
4. STN-YG, STN-blue, STN-Gray, FSTN-Positive display results as option
RYD160160A is 3"160x160 lcd display controller uc1698 cog module,8-bit parallel interface,fstn lcd,3v,wide temp.
PRODUCT DETAILS
ABOUT US
Royal Display Co., Ltd has been specializing in LCD business for more than 10 years, products range LCD Display, LCD Screen, LCD Module, Character LCD, LED backlight display, TFT display, Graphic LCD, 7 segment LED Display.
More than 90% of our products is specially customer designed to be used in Video and Audio system, financial, medical, industry equipment, testing devices, Electronic meters, facsimiles, many kinds of terminal equipment and so on. With the capability of 300K different kinds of LCM/LCD per month.
Our products have passed international quality certificates, including CE, FCC & RoHS. With high quality and competitive prices. We are looking forward to working together with you and establish long term business.
RELATED PRODUCTS
APPLICATION
OUR ADVANTAGE
1). Quality Control: Every LCD tested with special instruments or main boards before delivery to ensure working. Both Original and High quality OEM products available.
2). Packing: Packed in anti-static bags with foam box to ensure safety in transportation.
3). Payment Terms: T/T, Western Union.
4). Shipping Methods: Prompt delivery by UPS, EMS, DHL, TNT, or by air.
5). Service: Best after-sales service to ensure satisfaction from customers.
6). Delivery: Goods will be delivered with 2-4 days by DHL, UPS, TNT, EMS, or By Air
7). Warranty: Usually, product warranty for one year.
8). Samples: Our company offers samples for quality test or other business purposes, but we kindly ask you to pay for samples and the freight.
CONTACT US
The professional manufacturer of LCD, LCD module, and LED backlight
Contact Person: Wendy Zou
Address: 510 Yingshuo Building, IADC Sha Pu Songgang Town, Baoan District, Shenzhen, China 518105
Tel@: +86 188 2506 6373 +86 0755 2832 5455
Website: http://royaldisplay.en.made-in-china.com
PRODUCT DESCRIPTION
1. 160x160dots
2. Parallel interface
3. Ultra high contrast, YG & White LED backlight as option
4. STN-YG, STN-blue, STN-Gray, FSTN-Positive display results as option
| Item | Description |
| Product Name | 160x160dots Graphic LCD Module |
| Model No. | RYD160160A |
| Dot Format | 160x160 |
| Outline (mm) | 41*35 |
| Viewing Area(mm) | 12:00 |
| Pixel Size( mm) | 0.43 x 0.42 |
| Viewing Angle | 12 O' clock |
| LCD Type | FSTN-Positive, STN-Gray |
| Backlight | White or Amber LED backlight |
| Driver IC | UC1698 |
| Power supply | 3V |
| Interface | Parallel |
| Operating Temp | -20º C~70ºC |
| Storage Temp | -30º C~80ºC |
RYD160160A is 3"160x160 lcd display controller uc1698 cog module,8-bit parallel interface,fstn lcd,3v,wide temp.
